Branded controller system.
Full AC drive system, small size, light weight, maintenance-free.
Foldable standing pedal and side safety arms.
High-Quality Damping Spring.
The high-quality hydraulic pump.
Anti-slippery function.
reverse button, Lifting and lowering button)
Ergonomics designed control handle integrates multiple control (Acceleration, Horn, Emergency
Model
Rated Load
Max. Lifting Height
ATLAPEX electric pallet truck adopts the most scientificand advancing design ideas. lt is second to none.Hold the firm belief that the forklift can greatly improveyour warehouse space andimprove your efficiency.
1-Ergonomic and comfortable platformfor easy operation.
2-It offers a supporting functionto ensure stability.
1-With adjustable forged forks
5-Big load, flexible operation,compact structure suits forfactory & warehouse use.
4-Save your energy to improve the efficiency.
| Model | CBD20Ⅲ | CBD25Ⅲ | CBD30Ⅲ | CBD40Ⅲ | CBD50Ⅲ |
| Power | Electric | Electric | Electric | Electric | Electric |
| Operating Type | Standing Type | Standing Type | Standing Type | Standing Type | Standing Type |
| Steering Model | EPS | EPS | EPS | EPS | EPS |
| Load Capacity | 2000kg | 2500kg | 3000kg | 4000kg | 5000kg |
| Load Center | 600mm | 600mm | 600mm | 600mm | 600mm |
| Wheel Base | 1380mm | 1380mm | 1380mm | 1495mm | 1455mm |
| Self-weight With Battery | 690kg | 700kg | 710kg | 910kg | 1035kg |
| Wheel Type | PU | PU | PU | PU | PU |
| Front Wheel | φ80*80mm | φ80*80mm | φ80*80mm | φ80*80mm | φ80*110mm |
| Rear Wheel | φ230*75 | φ230*75mm | φ230*75mm | φ230*75mm | φ254*102mm |
| Balance Wheel | φ125*50 | φ125*50mm | φ125*50mm | φ125*50mm | φ150*50mm |
| Max Lifting Height | 205mm | 205mm | 205mm | 210mm | 225mm |
| Fork Outer Width | 685/540mm | 685/540mm | 685/540mm | 685mm | 720mm |
| Vehicle Body Length | 1825/2240mm | 1825/2240mm | 1825/2240mm | 1950/2365mm | 1950/2365mm |
| Vehicle Boy Width | 760 | 760mm | 760mm | 850mm | 850mm |
| Fork Size | 1150/175/55mm | 1150/175/55mm | 1150/175/55mm | 1200/180/60mm | 1200/215/70mm |
| Aisle Width,Pallet 1000×1200 | 2220/2620mm | 2220/2620mm | 2220/2620mm | 2520/2925mm | 2520/2925mm |
| Min Turning Radius | 1670/2070mm | 1670/2070mm | 1670/2070mm | 1785mm | 1785mm |
| Driving Speed(Unload/Load) | 6/5.5km/h | 6/5.5km/h | 6/5km/h | 5/4km/h | 5/4km/h |
| Lifting Speed(Unload/Load) | 0.043/0.04m/s | 0.043/0.04m/s | 0.043/0.04m/s | 0.045/0.043m/s | 0.042/0.04m/s |
| Lowering Speed(Unload/Load) | 0.035/0.445m/s | 0.035/0.445m/s | 0.035/0.445m/s | 0.035/0.048m/s | 0.35/0.045m/s |
| Max.gradeability(Unload/Load) | 10/8% | 10/8% | 10/6% | 10/6% | 8/5% |
| Service Brake | Electromagnetic | Electromagnetic | Electromagnetic | Electromagnetic | Electromagnetic |
| Drive Motor | 1.5kw | 1.5kw | 1.5kw | 2.5kw | 3kw |
| Lift Motor | 0.8kw | 0.8kw | 0.8kw | 2.2kw | 3kw |
| Battery | Lead Acid | Lead Acid | Lead Acid | Lead Acid | Lead Acid |
| Battery Voltage/Nominal Capacity | 24V/210Ah | 24V/210Ah | 24V/210Ah | 24V/280Ah | 24V/300Ah |
| Charge | 24V/30Ah | 24V/30Ah | 24V/30Ah | 24V/40Ah | 24V/40Ah |
| Charger | AC | AC | AC | AC | AC |
| Type Of Drive Control | 75dB | 75dB | 75dB | 75dB | 75dB |
