Branded control system with automated safety features.
Branded vertical gearbox, versatile modular construction, optimized gear technology forefficiency and reduced noise.
EPS reduces consumption by 20%, improves accuracy, reduces driver fatigue, and increasesproductivity.
Shock-absorbing spring adjusts the vertical drive unit for smoother operation and reduced impacton the drive system.
EPO(Emergency Power Off) switch for safety.
Rated Load
Max Lifting Height
ATLAPEX electric pallet stacker adopts the most scientific and advancing design ideas. lt is second to none.Hold the firm belief that the forklift can greatly improve your warehouse space and improve your efficiency.
1-With adjustable forged forks
2-Ergonomic and comfortable platformoffer operator a comfortable condition
3-EPO(Emergency Power Off) switch for safety.
| Model | CDD15 | CDD20 | CDD25 | CDD30 |
| Power | Electric | Electric | Electric | Electric |
| Operating Type | Standing Type | Standing Type | Standing Type | Standing Type |
| Load Capacity | 1500kg | 2000kg | 2500kg | 3000kg |
| Load Center | 500mm | 500mm | 500mm | 500mm |
| Bearing Distance | 676mm | 676mm | 790mm | 790mm |
| Wheel Base | 1380mm | 1430mm | 1577mm | 1577mm |
| Total Weight(With Battery) | 1115kg | 1115kg | 1632kg | 1632kg |
| Wheel Type | PU | PU | PU | PU |
| Front Wheel | φ80*70mm | φ80*70mm | φ85*90mm | φ85*90mm |
| Rear Wheel | φ230*75mm | φ230*75mm | φ230*75mm | φ254*104mm |
| Front Wheelbase | 490mm | 490mm | 530mm | 530mm |
| Rear wheelbase | 658mm | 658mm | 758mm | 758mm |
| Mast Lowered Height | 2060mm | 2060mm | 2188mm | 2188mm |
| Lift Height | 3000mm | 3000mm | 3000mm | 3000mm |
| Height,mast entended | 3541mm | 3541mm | 3571mm | 3571mm |
| Handle Height | 1430mm | 1430mm | 1430mm | 1430mm |
| Fork Clearance When last Lowered | 85mm | 86mm | 95mm | 95mm |
| Overall Length | 2185/2605mm | 2185/2605mm | 2235/2655mm | 2235/2655mm |
| Overall width | 850mm | 850mm | 1000mm | 1020mm |
| Fork Size | 1150/190/65mm | 1150/190/65mm | 1150/230/75mm | 1150/230/75mm |
| Fork Spread | 680mm | 680mm | 760mm | 760mm |
| Min. Ground Clearance | 30mm | 30mm | 30mm | 30mm |
| Min. Turning Radius | 1729/2130mm | 1729/2130mm | 1880mm | 1880mm |
| Travel Speed(Unload/Load) | 5.5/5km/h | 5.5/5km/h | 5/4km/h | 5.5/4km/h |
| Lifting Speed(Unload/Load) | 0.1/0.09m/s | 0.1/0.086m/s | 0.117/0.08m/s | 0.117/0.08m/s |
| Lowering Speed(Unload/Load) | 0.082/0.11m/s | 0.082/0.123m/s | 0.082/0.140m/s | 0.082/0.140m/s |
| Max.gradeability(Unload/Load) | 8/6% | 8/4% | 6/4% | 6/4% |
| Service Brake | Electromagnetic | Electromagnetic | Electromagnetic | Electromagnetic |
| Drive Motor | 1.5kw | 1.5kw | 2.5kw | 3kw |
| Lift Motor | 2.2kw | 2.2kw | 3kw | 3kw |
| Battery | Lead Acid | Lead Acid | Lead Acid | Lead Acid |
| Battery Voltage/Nominal Capacity | 24V/210Ah | 24V/210Ah | 24V/210Ah | 24V/210Ah |
| Charge | 24V/30Ah | 24V/30Ah | 24V/30Ah | 24V/30Ah |
| Charger | AC | AC | AC | AC |
| Type Of Drive Control | 75dB | 75dB | 75dB | 75dB |
